Stress Relief

Manufacturing processes such as heavy machining, electrical discharge machining (EDM), welding and production cycles are known to induce both thermal and mechanical stresses into metals.

In the case of heavy machining and or EDM, there can be an actual phase transformation at the affected surface this surface heat treatment can manifest itself in the final surface finish, especially in lens quality polishes and fine stipple textures.

Whitfield Welding will thermally stress relieve and temper at the same time with our oven procedures.


Capabilities

25 metric ton crane capacity

Ovens monitored with automation software for quality assurance

Rockwell Testing performed before and after treatment

Complete temperature reports provided with every job

Ovens have a combined capacity of 160,000 lbs for stress relief – these furnaces run 24/7 for quick turnaround




Furnace Specifications

UBC1 (LxWxH) 165"x65"x70" - 1200F max temp

UBC2 & UBC3: (LxWxH) 62″x45″x40″ - 1200F max temp

UBC4: (LxWxH) 143"x92"x69" - 1200 F max temp

PT1 UBC5: (LxWxH) 24"x24"x13" - 1400 F max temp

Amazing: (LxWxH) 23"x13"x11" - 1850 F max temp
